Bianchi Methanol CV FS

Tech specs

• Frameset

  1. Frame

     Methanol CV FS 100mm 29" full carbon HM monocoque w/Countervail, 1.5" tapered HT, BB92, only 1x drivetrain, PM 160mm carbon dropout, 12x148mm BOOST, internal cable routing, seatpost diam. 31,6mm, shock lenght/travel 190/40mm w/eyelets 20mm x diam.8mm, siz

  2. Fork

     Fox 34 SC 29"Performance remote, 120mm travel

  3. RearShock

     Fox Float DPS Performance Elite Remote

  4. Headset

     Fsa Orbit C-40

• Drivetrain

  1. Shifters

     Shimano XT SL- M8100R 12sp

  2. Rear Derailleur

     Shimano XT RD-M8100-SGS Shadow Design + 12sp

  3. Crankset

     Shimano XT FC-M8100-1 32T, 52mm chainline, crank length: 170mm-15", 175mm-17/21"

  4. Bottom Bracket

     Shimano BB-MT800-PA Pressfit 41x92mm

  5. Chain

     Shimano CN-M7100 12sp

  6. Cassette

     Shimano CS-M8100-12, 10-51T

• Brakes

  1. Brakes

     Shimano XT BR-M8100

  2. Rotor

     Shimano RT-64, 180mm & 160mm

• Wheels

  1. Wheels

     DT Swiss M1700 Spline two 29" 25mm

  2. Tire

     Kenda Nevegal2 Pro 29x2.20

• Cockpit

  1. Stem

     Tec Cursus, 3D forged AL7050-T6 w/forged alloy faceplate, +/-7º, 1.1/8", diam. 31.8mm, ext:60mm-15/17", 70mm-19/21"

  2. Handlebar

     Tec Cursus rise, double butted AL2014-T6, width 760mm, diam. 31,8mm, rise 15mm, 9° backsweep

  3. Grips

     T-One Rock T-GP34

• Saddle

  1. Seatpost

     Dropper Seatpost diam.31,6mm, internal remote cable routing w/remote control 1x drivetrain specific, travel: 100mm-15", 125mm-17/21"

  2. Saddle

     Fi'zi:k Taiga

• Accessories

  1. Pedals

     included

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
