Neat and tidy performance e-mtb, with front suspension aluminum frame.

Off-road riding, mountain, hilly courses.

For the biker who wants to shred just about anything.

• Aluminium frame
• Travel: 120mm
• Motor: Bianchi 250W – 85Nm, 5 level of assistance
• Battery: 418 or 504Wh
• Wheel size: 29x2.35
• Boost 9x141mm QR rear dropout
• Internal cable routing
• 4 sizes (S, M, L, XL)

Specifiche Tecniche

Tech specs

  • Motor Unit

    1. Motor

      Bianchi Motor Unit 250W 85Nm w/Phylion 504Wh battery
  • Frameset

    1. Frame

      T-Tronik Sport HT, alu 6061 triple butted, 1.5" tapered HT, seatpost diam. 31.6mm, seatpost clamp diam. 34.9mm, PM 160mm, Boost dropout QR 12x141mm, internal cable routing, sizes 38-43-48-53cm
    2. Fork

      SR Suntour XCR34 AIR Boost LOR DS 29" 120mm
    3. Headset

      Fsa Orbit 1.5 ZS
  • Drivetrain

    1. Shifters

      Shimano Deore SL- M6000 10sp
    2. Rear Derailleur

      Shimano Deore RD-M6000-GS Shadow Plus Design 10sp
    3. Crankset

      Fsa Alu crank w/34T chainring, 104BCD, length: 165mm
    4. Bottom Bracket

      Included w/motor unit
    5. Chain

      Kmc X10eS EPT finish
    6. Cassette

      Shimano CS-HG500-10, 11-13-15-18-21-24-28-32-37-42T
  • Brakes

    1. Brakes

      Shimano BR-MT401
    2. Rotor

      Shimano SM-RT10 CL, diam. 180mm
  • Wheels

    1. Wheels

      Wtb XC25 TCS rim Tubeless Ready 29"
    2. RearHub

      Shimano FH-MT200-B
    3. FrontHub

      Shimano HB-MT400-B
    4. Tire

      Kenda Slant Six Sport 29x2.35
  • Cockpit

    1. Stem

      Tec Obvius forged alloy 6061, +/-7°, 1.1/8", 31.8mm, ext: 60mm-15/19", 70mm-21"
    2. Handlebar

      Tec rise, DB Alloy 6061-T6, width 740mm, diam. 31,8mm, 9° backsweep, 15mm rise
    3. Grips

      T-One Rock T-GP34
  • Saddle

    1. Seatpost

      Tec AL2014 shaft and alloy head, diam 31.6mm, 0mm setback, length: 350mm-15/17'', 400mm-19/21''
    2. Saddle

      Tec Rector, Steel rails
  • Accessories

    1. Pedals


Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
