Bianchi Infinito XE

Tech specs

• Frameset

  1. Frame

     Infinito XE Disc carbon, tapered HT 1.1/8"- 1.5", Mechanical/Electronic Di2 shifting compatible, compatible with 32" tire, PressFit 86,5x41mm BBset, thru axle 12x142mm, sizes 47-50-53-55-57-59-61cm

  2. Fork

     Bianchi Full Carbon Disc, 1.5" head, thru axle 12x100mm, compatible with 32" tire

  3. Headset

     Fsa NO.42/47CF/ACB/5D

• Drivetrain

  1. Shifters

     Shimano 105 ST-R7020 2x11sp, Hydraulic disc brake, Shimano 105 ST-R7025 2x11sp smaller lever size for sizes 47-50-53cm

  2. Rear Derailleur

     Shimano 105 RD-R7000 GS 11sp

  3. Front Derailleur

     Shimano 105 FD-R7000-L

  4. Crankset

     Shimano 105 FC-R7000 50x34T, Hollowtech II, crank length: 170mm-47/53cm, 172.5mm-55/59cm, 175mm-61cm

  5. Bottom Bracket

     Shimano SM-BB71-41B, PressFit

  6. Chain

     Kmc X11-1 EPT finish, 11sp

  7. Cassette

     Shimano 105 CS-R7000, 11-12-13-14-16-18-20-22-25-28-32T

• Brakes

  1. Brakes

     Shimano BR-RS505

  2. BrakeLevers

     included w/shifters

  3. Rotor

     Shimano SM-RT70, diam. 160mm

• Wheels

  1. Wheels

     Fulcrum Racing 918 disc brake

  2. Tire

     Vittoria Zaffiro Pro V 700x28

• Cockpit

  1. Stem

     Reparto Corse, 3D Forged Alloy 6061, rise +/- 7°, 1.1/8", AL6061 faceplate, Ext: 70mm-47cm, 90mm-50cm, 100mm-53cm, 110mm-55cm, 120mm-57/61cm

  2. Handlebar

     Reparto Corse , Flat Top, alloy 6061 diam. 31,8mm, reach 80mm, drop 130mm, Size: 400mm-47/53cm, 420mm-55/59cm, 440mm-61cm

  3. Grips / Extensions

     La Spirale Ribbon cork

• Saddle

  1. Seatpost

     Reparto Corse, AL2014 shaft, AL6061 head, 25mm offset, length: 350mm-47/57cm, 380mm-59/61cm

  2. Saddle

     Bianchi, steel rail, w/open, 250x148mm

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
