Bianchi Oltre XR4

Tech specs

• Frameset

  1. Frame

     Oltre XR4 carbon w/Bianchi CV, mechanical/electronic shifting compatible, head tube 1.1/4" - 1.1/8", direct mount brakes, PressFit 86,5x41mm BB,sizes 44-47-50-53-55-57-59-61cm

  2. Fork

     Bianchi Full Carbon Aero w/Bianchi CV, 1.1/8>1.1/4"

  3. Headset

     Fsa Orbit C-33, 1.1/8”-1.1/4”, w/Carbon custom top cap for normal stem

• Drivetrain

  1. Shifters

     Shimano Ultegra ST-R8000 2x11sp

  2. Rear Derailleur

     Shimano Ultegra RD-R8000 SS 11sp

  3. Front Derailleur

     Shimano Ultegra FD-R8000

  4. Crankset

     Shimano Ultegra FC-R8000 50x34T, Hollowtech II, Crank Length: 165mm-44cm, 170mm-47/53cm, 172.5mm-55/59cm, 175mm-61cm

  5. Bottom Bracket

     Shimano SM-BB72-41B

  6. Chain

     Shimano Ultegra CN-HG701-11, 11sp

  7. Cassette

     Shimano Ultegra CS-R8000, 11-12-13-14-15-17-19-21-24-27-30T

• Brakes

  1. Brakes

     Shimano Ultegra BR-R8010, direct mount

  2. Brake Levers

     included w/shifters

• Wheels

  1. Wheels

     Vision Trimax 35 700x19c, clincher

  2. Tire

     Vittoria Corsa G2.0 graphene 700x25

• Cockpit

  1. Stem

     Reparto Corse, 3D Forged alloy 6061, rise +/ - 7°, 1.1/8", Ext: 70mm-44/47cm, 90mm-50cm, 100mm-53cm, 110mm-55cm, 120mm-57/61cm

  2. Handlebar

     Reparto Corse Aero Compact, alloy 2014 diam. 31,8mm, reach 80mm, drop 130mm, Size: 400mm-44/50cm , 420mm-53/57cm, 440mm-59/61cm

  3. Grips / Extensions

     Black soft Microfiber tapes w/shockproof Eva-139

• Saddle

  1. Seatpost

     Oltre Full Carbon Aero, clamp with alloy head adjustable and reversible +/- 35mm, length: 250mm-44/47cm, 300mm-50/53cm, 350mm-55/59cm, 380mm-61cm, Setback: 25mm/-10mm

  2. Saddle

     Fi'zi:k Argo Vento R3, K:ium rails, 260x140mm

• Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
