Designed for

Challenging off-road trails. For hardcore e-racer or for exploration and enjoyment.

Riding Conditions

Riding on rough terrain with drops of less than 122 cm.









Daily use

Tech specs

  • Motor Unit

    1. Motor

      Shimano EP8 drive unit, 250W, 85Nm
    2. Battery

      720Wh integrated battery
  • Frameset

    1. Frame

      Bianchi e-SUV Carbon sizes: 43, 48, 53 - 12x148 mm thru axle dropouts - Post mount 180 disc brake type - 1.5" tapered head tube - seatpost diam. 31,6mm - 150mm travel front & rear - compatible to 160mm travel front
    2. Fork

      RockShox ZEB Select 29", 150mm travel, 15x110 BOOST, minimum 200mm rotor, maximum 220mm rotor, 44mm rake, 63mm crown, DebonAir+, extl rebnd, 38mm stanchions
    3. RearShock

      RockShox Deluxe Select +, DebonAir Linear, Damer Type RL, Compression Tune M, Lockout Force 430, external rebound adjustment, Volume reducer 0 Neg 1 Pos
    4. Headset

      FSA NO.55R/558 1.5"
  • Drivetrain

    1. Shifters

      SRAM GX EAGLE, 1x12sp
    2. Rear Derailleur

      SRAM GX EAGLE, 12sp
    3. Crankset

      Shimano, FC-EM600, 165MM - SRAM chainring XSYNC2 34T
    4. Bottom Bracket

      Included w/motor unit
    5. Chain

      Sram NX Eagle 12sp
    6. Cassette

      SRAM PG1230, 12sp, 11-13-15-17-19-22-25-28-32-36-42-50T
  • Brakes

    1. Brakes

      Shimano BR-M6120, 4 pistons caliper
    2. BrakeLevers

      Shimano BL-M6100
    3. Rotor

      Shimano SM-RT64 ant. diam. 203mm - Shimano RT-EM600 post. diam. 203mm
  • Wheels

    1. Wheels

      Dt Swiss H1900 Spline Front: 29", 30mm width, 15x110TA - Rear: 27,5", 35mm width, 12x148TA
    2. Tire

      Front: Kenda Hellkat 29x2.6 - Rear: Regolith 27,5x2.8
  • Cockpit

    1. Stem

      Velomann +/-0°, diam.35mm, ext: 50mm
    2. Handlebar

      Velomann, width 780mm, diam.35mm, rise 20mm, backsweep 9°
    3. Grips

      T-One Rock T-GP34
  • Saddle

    1. Seatpost

      Velomann, diam.31,6mm, 125mm travel for size 43, 150mm travel for size 48, 53
    2. Saddle

      Fi'zi:k Alpaca Terra, S alloy rail, 249x145mm
  • Accessories

    1. Mudguards

      Front & rear integrated mudguards
    2. FrontLight

      Spanninga integrated front light
    3. RearLight

      Spanninga integrated rear lights

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
