Bianchi Methanol FS 9.1

Tech specs

• Frameset

  1. Frame

     Methanol FS 100mm 29" full carbon monocoque HM, 4-bar linkage, 1.5" tapered HT, PF30, HDM FD, PM 160mm carbon dropout, 12x142 Shimano e-thru, internal cable routing, seatpost 31,6mm, shock 165/38mm, sizes 17,19,21"

  2. Fork

     Fox 32 SC 29" Factory Kashima remote, 100mm travel

  3. Rear Shock

     Fox Float DPS Factory Kashima Remote

  4. Headset

     Fsa Orbit 1.5 ZS

• Drivetrain

  1. Shifters

     Sram XX1 Eagle 12sp trigger

  2. Rear Derailleur

     Sram XX1 Eagle 12sp

  3. Crankset

     Sram XX1 Eagle DUB 32T, carbon arms, 49mm chainline, 168mm Q- Factor, Direct Mount, crank length: 175mm-17/21"

  4. Bottom Bracket

     Sram DUB PF30, 68-92

  5. Chain

     Sram PC-XX1 EAGLE 12sp

  6. Cassette

     Sram XG-1295 Eagle 10-12-14-16-18-21-24-28-32-36-42-50T

• Brakes

  1. Brakes

     Sram Level Ultimate

  2. Rotor

     Sram Centerline X, 180mm front, 160mm rear

• Wheels

  1. Wheels

     DT Swiss XR1501 Spline 29" 25mm (standard)

  2. Tire

     Kenda Honey Badger XC Pro 29x2.20

• Cockpit

  1. Stem

     Fsa K-Force Light OS-100 CSI, 3D forged/machined AL7050 w/Ti bolts sculpted AL2014/Carbon faceplate, +/-12º, 1.1/8", 31.8mm, ext: 90mm-17", 100mm-19/21"

  2. Handlebar

     Fsa K-Force Light flat UD carbon/Kevlar composite, width 700mm, diam. 31.8mm, backsweep 6°, upsweep 0°

  3. Grips / Extensions

     T-One T-GP43X

• Saddle

  1. Seatpost

     Fsa K-Force Light UD carbon monocoque w/2-bolts MTC head, 31.6mm, 25mm seatback, Di2 compatible, length: 400mm-17/21"

  2. Saddle

     Fi'zi:k Tundra M3, carbon braided rail, 290x125mm

• Accessories

  1. Pedals

     included

• Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
