Bianchi Oltre XR4

Tech specs

• Frameset

  1. Rahmen

     Oltre XR4 carbon w/Countervail, mechanical/electronic shifting compatible, headset 1.5", PressFit 86,5x41mm BB, Disc brake internal cable routing, flat mount calipers, thru axle 12x142mm, sizes 47-50-53-55-57-59-61cm

  2. Gabel

     Bianchi Full Carbon aero Disc, 1.5" integrated head, Disc Brake internal cable routing, flat mount caliper, thru axle 12x100

  3. Headset

     Fsa Orbit, 1.5", specific for Metron ACR integrated handlebar

• Drivetrain

  1. Schalthebel

     Shimano Dura Ace Di2 ST-R9170 2x11sp

  2. Schaltwerk

     Shimano Dura Ace Di2 RD-R9150 SS 11sp

  3. Umwerfer

     Shimano Dura Ace Di2 FD-R9150-F

  4. Kurbelgarnitur

     Shimano Dura Ace FC-R9100, Hollowtech II, 52x36T, Crank Length: 170mm-47/53cm, 172.5mm-55/59cm, 175mm-61cm

  5. Bottom Bracket

     Shimano SM-BB92-41B PressFit

  6. Kette

     Shimano Dura Ace CN-HG901-11

  7. Kassette

     Shimano Dura Ace CS-R9100, 11-12-13-14-15-17-19-21-23-25-28T

• Brakes

  1. Bremsen

     Shimano BR-R9170 Hydraulic disc brake, flat mount caliper

  2. Bremshebel/griffe

     included w/shifters

  3. Bremsscheibe

     Shimano SM-RT900 Center Lock 160mm

• Wheels

  1. Laufradsatz

     DT Swiss ARC 1100 Dicut DB, full carbon 62mm

  2. Reifen

     Vittoria Corsa G+ Isotech graphene, 700x25c

• Cockpit

  1. Vorbau

     included with handlebar

  2. Lenker

     Vision Metron 5D ACR Disc Integrated Aero bar, material UD Weave Carbon, drop 125mm, reach 80mm, Di2 compatible, Ext: 100x400mm-47/50cm, 110x420mm-53/55cm, 120x420mm-57/59cm, 130x440mm-61cm

  3. Griffe

     Black soft Microfiber tapes w/shockproof Eva-139

• Saddle

  1. Sattelstütze

     Oltre Full Carbon Aero; clamp with alloy head adjustable and reversible +/- 35mm, length: 250mm-47cm, 300mm-50/53cm, 350mm-55/59cm, 380mm-61cm, Setback: 25mm/-10mm

  2. Sattel

     Fi'zi:k Arione R1

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
