Bianchi T-Tronik Rebel 9.2

Tech specs

• Motor Unit

  1. Motor

     Bianchi Motor Unit 250W 85Nm w/630Wh battery

• Frameset

  1. Rahmen

     T-Tronik Rebel FS 140mm alu 6061 triple butted, 1.5" tapered HT, seatpost diam. 31,6mm, seat clamp diam. 34.9mm, PM 160mm dropout thru axle 12x148mm, internal cable routing, sizes 38-43-48-53cm

  2. Gabel

     Rock Shox Recon RL 29B" Solo Air, 140mm

  3. Dämpfer

     Rock Shox Deluxe Select+ RL, 185/50 TR

  4. Headset

     Fsa Orbit 1.5 ZS

• Drivetrain

  1. Schalthebel

     Sram SX Eagle 12sp, trigger single click for e-bike

  2. Schaltwerk

     Sram NX Eagle 12sp, long cage

  3. Kurbelgarnitur

     Fsa Aluminium crank w/Eagle 34T chainring, length 165mm

  4. Bottom Bracket

     Included w/motor unit

  5. Kette

     Sram SX Eagle 12sp

  6. Kassette

     Sram PG1210 12sp, 11-50T

• Brakes

  1. Bremsen

     Shimano BR-MT520

  2. Bremsscheibe

     Shimano SM-RT30 CL, diam. 203mm

• Wheels

  1. Laufradsatz

     WTB ST Light i30 TCS 2.0 29"

  2. Hinterradnabe

     Shimano FH-MT400-B

  3. Vorderradnabe

     Shimano HB-MT400-B

  4. Reifen

     Kenda Hellkat 29x2.6

• Cockpit

  1. Vorbau

     Tec Obvius, 0°, 1.1/8", diam. 31.8mm, ext: 55mm

  2. Lenker

     Tec Obvius rise, AL6061-T6 double butted, width 780mm, diam. 31.8mm, 15mm rise, 9° backsweep

  3. Griffe

     T-One Rock T-GP34

• Saddle

  1. Sattelstütze

     Dropper seatpost, diam 31.6mm, internal remote cable routing w/remote 1x specific, travel: 100mm-15'', 120mm-17'', 150mm-19/21''

  2. Sattel

     Tec Rector, Steel rails

• Accessories

  1. Pedale

     included

• Based on component availability, Bianchi reserves the right to make changes on specifications without notice.

Size Frame & Geometry
