Bianchi e-SUV Rally

Tech specs

• Motor Unit

  1. Motor

     Shimano EP8 motor unit w/DU-EP800 drive unit, 34T chainring, speed sensor w/720Wh integrated battery

• Frameset

  1. Rahmen

     Bianchi E-SUV 150mm Full Carbon, 1.5" tapered HT, seatpost diam. 31,6mm, integrated seat clamp, PM180mm dropout, thru axle 12x148mm, internal cable routing inside DT, sizes 43, 48, 53cm

  2. Gabel

     Fox 38 Float 29" Factory, e-MTB version, 150mm travel

  3. Dämpfer

     Fox Float DPX2 Factory

  4. Headset

     Fsa NO.55R/558 1.5"

• Drivetrain

  1. Schalthebel

     Shimano XTR SL- M9100IR 1x12sp

  2. Schaltwerk

     Shimano XTR RD-M9100SGS Shadow+ Design 12sp

  3. Kurbelgarnitur

     Shimano FC-EM600 Alu crank 165mm, 24mm axle w/custom chainguide for 30-38T

  4. Bottom Bracket

     Included w/motor unit

  5. Kette

     Shimano CN-M8100, 12sp

  6. Kassette

     Shimano CS-M8100-12, 10-51T

• Brakes

  1. Bremsen

     Shimano BL-M8120, 4 pistons brakes

  2. Bremsscheibe

     Shimano front RT-MT800 & rear RT-EM810 with magnet for speed sensor, diam. 203mm front & rear, Center Lock

• Wheels

  1. Reifen

     Front: Kenda Hellkat 29x2.6, Rear: Kenda Regolith 27,5x2.8

• Cockpit

  1. Vorbau

     integrated with handlebar

  2. Lenker

     Bianchi integrated carbon handlebar-stem, rise +6°, 800mm width, stem length: 40mm, 7° backsweep, 5°upsweep, 25mm rise

  3. Griffe

     T-One Rock T-GP34

• Saddle

  1. Sattelstütze

     Fox Transfer Factory, diam 31,6mm, travel: 125mm-17", 150mm-19,21"

  2. Sattel

     Fi'zi:k Alpaca Terra, S alloy rail, 249x145mm

• Accessories

  1. Schutzblech

     Front and rear, integrated

  2. Frontleuchte

     Spanninga integrated front lights + Lupine SL-F Shimano

  3. Hinterradnabe

     Spanninga integrated rear lights

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
