Tech specs

  • Motor Unit

    1. Motor

      Bosch Performance Line CX 250W 85Nm
    2. Battery

      Bosch Powertube 625Wh
  • Frameset

    1. Frame

      e-Omnia FT Type Alloy FS 29"" 100mm, 1.5"" tapered HT, seatpost diam. 31,6mm, integrated seat clamp, PM 180mm dropout thru axle 12x148mm, internal cable routing inside DT, Hanger compatible UDH, sizes 43,48,53cm (MD; LG; XL)
    2. Fork

      Rock Shox Recon Silver RL 29B" Solo Air, 120mm
    3. RearShock

      Rock Shox Deluxe Select+ RL
    4. Headset

      Fsa NO.55R/558 1.5"
  • Drivetrain

    1. Shifters

      Shimano Deore SL-M6100-IR 1x12sp
    2. Rear Derailleur

      Shimano XT RD-M8100-SGS Shadow+ Design 12sp, top normal, max 10-51T
    3. Crankset

      Fsa Forged Alu, crank length 165 mm, ISIS BB axle, w/Shimano SM-CRE80-12 chainring 34T, w/custom chainguide 30-38T
    4. Bottom Bracket

      included in the motor
    5. Chain

      Shimano CN-M7100, 12sp
  • Brakes

    1. Brakes

      Shimano BR-MT520, 4 piston calipers, resin pad, w/203mm front & rear adapter, I-SPEC II compatible
    2. Rotor

      Shimano front:RT-64 FRONT & rear: RT-EM600 w/speed sensor magnet, diam. 203mm, Center Lock
  • Wheels

    1. Wheels

      Velomann ST30 TCS 2.0 29”, 30mm internal width
    2. RearHub

      Formula FH-MT510-B, Center Lock, BOOST 12x148mm, Shimano Microspline 12sp body
    3. FrontHub

      Formula CL-811 Center Lock, 15x110mm TA
    4. Tire

      Schwalbe Hurricane 29x2.25, Race Guard, compound Addix
  • Cockpit

    1. Stem

      Velomann ST97Q rise 0°, 1.1/8", diam. 35mm, length: 50mm
    2. Handlebar

      Velomann rise MTB488Q.7 double butted AL7050, width 720mm, diam. 35mm, rise 20mm, backsweep 9°
    3. Grips

      Rock T-GP34 single lock grip
  • Saddle

    1. Seatpost

      Velomann SP-7019 AL2014 shaft w/alloy head, diam. 31,6mm, 0mm seatback, length: 350mm-43cm, 400mm-48/53cm
    2. Saddle

      Velomann A037HR0 Gent, black steel rail, 285x187mm
  • Accessories

    1. Mudguards

      Bianchi custom chainguards
    2. Kickstand

      Velomann R78 KING EVO REAR max 35kg
    3. RearCarrier

      custom rear carrier integrated into the frame design
    4. FrontLight

      Integrated custom front and side light made w/Spanninga
    5. RearLight

      Integrated custom rear and side light made w/Spanninga

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
