Bianchi E-Doardo

Tech specs

• Motor Unit

  1. Motor

     Fazua Evation 1.0 Drive Pack, 250Wh Battery, w/remote control and speed sensor

• Frameset

  1. Frame

     Edoardo Alu triple hydroforming technology, integratd tapered headset 1,5", 700C, OLD 142mm thru axle, flat mount Disc, size: 45-50-55cm

  2. Fork

     Bianchi Edoardo Full carbon, thru axle, flat mount disc

  3. Headset

     Fsa Orbit C-40-ACB

• Drivetrain

  1. Shifters

     Shimano Metrea ST-U5060 11sp

  2. Rear Derailleur

     Shimano Metrea RD-U5000 SS 11sp

  3. Crankset

     Fsa 38T, crank length: 170mm

  4. Bottom Bracket

     Included in the Evation motor unit

  5. Chain

     Kmc X11eS EPT finish

  6. Cassette

     Shimano 105 CS-R7000, 11-12-13-14-16-18-20-22-25-28-32T

• Brakes

  1. Brakes

     Shimano Metrea BR-U5000

  2. Brake Levers

     Included w/Metrea shifters

  3. Rotor

     Shimano Metrea SM-RT500, diam 140mm

• Wheels

  1. Wheels

     Shimano Metrea WH-U5000

  2. Tire

     Vittoria Revolution 700x38

• Cockpit

  1. Stem

     3D forged AL6061, rise 7°, diam. 31,8mm, 1.1/8"

  2. Handlebar

     Pro H-type bar, width 42cm, diam 31.8mm

• Saddle

  1. Seatpost

     Carbon UD shaft, forged alloy head, 15mm offset, length: 300-350mm, diam.31,6mm

  2. Saddle

     Selle Royal Lookin Moderate, w/Royalgel, w/steel rails

• Accessories

  1. Pedals

     included

• Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
