Bianchi Magma 9.0

Tech specs

• Frameset

  1. Frame

     Magma 29" alu, 1,1/8" HT, BSA 68mm, seatpost diam. 27,2mm, low clamp FD diam. 31,8mm bottom pull or Side-Swing, PM 160mm, dropouts 9x135mm QR, internal cable routing, sizes 15-17-19-21"

  2. Fork

     SR Suntour XCR32 RL-R DS 29" 100mm

  3. Headset

     Fsa TH888

• Drivetrain

  1. Shifters

     Shimano Deore SL-M6000 2x10sp

  2. Rear Derailleur

     Shimano Deore RD-M6000-GS Shadow Plus Design 10sp

  3. Front Derailleur

     Shimano Deore FD-M6025-L

  4. Crankset

     Shimano FC-MT500-2 36/26T, crnk length: 170mm-15/17", 175mm-19/21"

  5. Bottom Bracket

     Shimano SM-BB52

  6. Chain

     Kmc X10 EPT finish

  7. Cassette

     Shimano CS-HG500-10, 11-13-15-18-21-24-28-32-37-42T

• Brakes

  1. Brakes

     Shimano BR-MT200

  2. Rotor

     Shimano SM-RT10, 160mm front & rear, Center Lock

• Wheels

  1. Wheels

     AlexRims DP2.5

  2. RearHub

     Formula CL-1422

  3. FrontHub

     Formula CL-1420

  4. Tire

     Kenda Honey Badger XC 29x2.20

• Cockpit

  1. Stem

     Tec Obvius 3D forged alloy 6061 anodized sandblasted, +/-7°, 1.1/8", diam. 31.8mm, lenght: 80mm-15/17", 90mm-19/21"

  2. Handlebar

     Tec Obvius flat DB Alloy 6061-T6, width 720mm, diam. 31,8mm, 9° backsweep

  3. Grips

     T-one T-GP48B

• Saddle

  1. Seatpost

     Tec Obvius Al2014 shaft with forged head, diam. 27.2mm, 20mm seatback, length: 350mm

  2. Saddle

     Tec Rector, Steel rails

• Accessories

  1. Pedals

     included

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
