Bianchi Arcadex

Tech specs

• Frameset

  1. Frame

     Arcadex Carbon, 1.5" headset, seatpost diam. 31.6mm, thru axle 12x142mm, flat mount caliper, Pressfit 41 BB, compatible with 42mm tire and mudguard predisposition, sizes: XS-SM-MD-LG-XL

  2. Fork

     Bianchi Full Carbon Disc, 1.5" head, flat mount caliper, thru axle 12x100mm

  3. Headset

     FSA SMR HS with 1.1/8” custom top cone Bianchi, H2475, Internal Headset, Integrated Alloy custom top cup 1.1/8", 1.5", 36°/45° ACB

• Drivetrain

  1. Shifters

     Shimano GRX 600 ST-RX600 1x11sp

  2. Rear Derailleur

     Shimano GRX RD-RX812 11sp

  3. Crankset

     Shimano GRX 600 FC-RX600 40T, Crank Length: 170mm-XS-SM, 172.5mm-MD-LG, 175mm-XL

  4. Bottom Bracket

     Shimano BB-RS500-PB, press fit

  5. Chain

     Kmc X11-1 EPT finish

• Brakes

  1. Brakes

     Shimano BR-RX400

  2. Brake Levers

     included w/shifters

  3. Rotor

     Shimano SM-RT70, diam. 160mm

• Wheels

  1. Wheels

     AlexRims GD24 disc 622-21, tubeless ready

  2. Rear Hub

     Shimano FH-RS470

  3. Front Hub

     Shimano HB-RS470

  4. Tire

     WTB Riddler Comp 700x37

• Cockpit

  1. Stem

     Reparto Corse by Fsa ST-OS-188/SMR-0°, Alloy 6061 , 1 1/4", rise 0°, Ext: 80mm-XS/S, 100mm-M, 120mm-L/XL

  2. Handlebar

     Reparto Corse Aluminum 6061, reach 70mm, flare angle 16°, drop cc 120 x size 40cm and 130mm, size: 40cm-XS/S, 42cm-M/L, 44cm-XL

  3. Grips / Extensions

     La Spirale Ribbon cork

• Saddle

  1. Seatpost

     Reparto Corse Alloy shaft AL6061, alloy head, 15mm offset, 31,6mm, Length: 300mm-XS, 350mm-S/M/L/XL

  2. Saddle

     Reparto Corse 2315HRN, rail steel black, open, cover PU, lenght/wide 250x148mm

• Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
