RIDING STYLE

Designed for

Pro riders always on the attack and fot those who want to keep the best aero position for longer.

Riding Conditions

Riding on paved roads.

Course/terrain

Road

Mixed

Trail

City

Activity

Race

Training

Daily use

Tech specs

  • Frameset

    1. Frame

      Oltre XR4 Disc carbon w/Bianchi CV, mechanical/electronic shifting compatible, headset 1.5", PressFit BB 86,5x41mm, Disc brake internal cable routing, flat mount, thru axle 12x142mm, sizes 47-50-53-55-57-59-61cm
    2. Fork

      Bianchi Full Carbon w/Bianchi CV, Disc, thru axle 12x100mm
    3. Headset

      Fsa Orbit custom 5D ACR top cover UD Carbon, lower 1.5"- top 1 .5", 36°- 45° ACB bearing, w/Carbon custom cone spacer specific for Metron DISC integrated handlebar, for 52mm/52mm OD head tube
  • Cockpit

    1. Stem

      Reparto Corse Metron 5D ACR Disc Integrated Aero bar, Bar/stem Integrated, material UD Weave Carbon, drop 125mm, reach 80mm, Di2 compatible, RC'21 graphics, Ext: 100x400mm-47/50cm, 110x420mm-53/55cm, 120x420mm-57/59cm, 130x440mm-61cm
    2. Handlebar

      included in the stem
  • Saddle

    1. Seatpost

      Reparto Corse Full Carbon Aero special dimension; special Clamp type with alloy head adjustable and reversible +/- 35mm; lenght: 250mm-47cm, 300mm-50/53cm, 350mm-55/59cm, 380-61cm, Setback: 25mm/+10mm

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.

Geometry

Oltre XR4 Disc
A1 A B1 C D E F G G1 H I X Y WB
470 420 513 410 58 105 579 74.5° 70.5° 43 368 377 490 982
500 450 523 410 58 110 581 74.5° 71.5° 43 368 384 499 983
530 480 535 410 68 125 582 74° 72° 43 368 385 525 984
550 500 550 410 68 140 588 73.5° 72.5° 43 368 390 541 988
570 520 560 412 68 155 593 73.5° 73° 43 368 395 557 995
590 540 575 412 68 175 603 73° 73° 43 368 398 576 1005
610 560 585 414 68 195 607 72.5° 73° 43 368 398 594 1011

Collection

Oltre XR4

Discover the product
