Tech specs

  • Frameset

    1. Frame

      Oltre RC carbon aero shape, electronic drivetrain only, headset 1.1/4"-1.1/4",BB-PressFit 86,5x41mm, integrated seat clamp, for flat mount caliper, internal cable routing for disc brakes, thru axle 12x142mm sizes 47-50-53-55-57-59cm
    2. Fork

      Full Carbon aero, Disc brakes, integrated head 1.1/4", flat mount caliper, thru axle 12x100mm
    3. Headset

      Fsa No. 54 - MR137 - ACB 1-1/4"diam.46.9x diam.37x7
  • Drivetrain

    1. Shifters

      Sram Red eTap AXS D1 Hydraulic Disc Brake, Stealth-a-majig disconnected, 20mm Flat Mount, 1000mm hose
    2. Rear Derailleur

      Sram Red eTap AXS D1 12sp
    3. Front Derailleur

      Sram Red eTap AXS D1
    4. Crankset

      Sram Red D1, 12sp Power Meter, 48/35, Crank Length: 170mm-47/53cm, 172.5mm-55/59cm
    5. Bottom Bracket

      Sram Press fit Road 86,5x41
    6. Chain

      Sram Red D1 12sp
  • Brakes

    1. Brakes

      Sram included in the shifter
    2. Rotor

      Sram centerlock centerline x Road 160mm
  • Wheels

    1. Wheels

      Reparto Corse Carbon SPB 50mm profile, 700x21c (front), Reparto Corse Carbon SPB 65mm profile, 700x21c, XDR body (rear), 3K and UD high strength carbon fiber, tubeless ready, weight per set: 1520 gr (+/-5%)
    2. Tire

      Pirelli P ZERO™ Race SL TLR , 28-622, 120 tpi
  • Cockpit

    1. Stem

      Integrated handlebar Integrated Aero bar, material Carbon, drop 125mm, reach 80mm, Di2 compatible Ext: 90x400-47/50cm ; 100x420-53cm ; 110x420-55/57cm; 120x440-59/61cm
    2. Handlebar

      included in the stem
    3. Grips

      Velo soft Microfiber tape, black
  • Saddle

    1. Seatpost

      Oltre Full Carbon Aero special dimension seatpost, 20mm offset, length: 280mm-47cm, 300mm-50/53cm, 350mm-55/59cm
    2. Saddle

      Bianchi RC139 Carbon Air, weight 168g, Lenght: 250mm, Wide: 139mm, Rails: 7 x 9,3mm

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.

Geometry

SIZE A B1 C D E F G G1 H I X Y WB
470 450 515 410 58 83 579 74.5° 70.5° 43 368 385 470 982
500 480 525 410 58 88 581 74.5° 71.5° 43 368 392 478 983
530 510 536 410 68 103 582 74° 72° 43 368 393 504 984
550 530 550 410 68 118 588 73.5° 72.5° 43 368 397 520 988
570 550 560 412 68 133 593 73.5° 73° 43 368 402 536 996
590 570 575 412 68 153 603 73° 73° 43 368 406 555 1005

Collection

Oltre RC
