RIDING STYLE
Designed for
Expert rider who loves to ride fast and in control no matter the terrain.
Riding Conditions
Riding on paved and unpaved roads with drops of less than 15 cm.
Course/terrain
Road
Mixed
Trail
City
Activity
Race
Training
Daily use
Tech specs
-
Frameset
Frame
Arcadex carbon, seat post 31.6mm, thru axle 12x142mm, flat mount disc , pressfit 41 , compatible with 42mm tire and mudguard. Sizes: XS-S-M-L-XLFork
Full Carbon 1.5" flat mount, disc brake, thru axle 12x100mmHeadset
FSA SMR HS with 1-1/8” custom top cone Bianchi
-
Drivetrain
Shifters
Shimano GRX Hydraulic disc brake, for 160mm rotorRear Derailleur
Shimano GRXCrankset
Shimano, 40T, Crank Length: 170mm-XS-S, 172.5mm-M-L, 175mm-XLBottom Bracket
Shimano, SM-BB72-41B, press fit for roadChain
Shimano, 105 12sp, CN-M7100
-
Brakes
Brakes
Shimano flat mount hydraulic disc brake, included in the shifterRotor
Shimano rotor for disc brake center lock, 160mm
-
Wheels
Wheels
Velomann alloy disc 700c 622-21, profile 27mm, Shimano RS470 hubs, 32hole, tubeless readyTire
WTB Resolute Comp 700 x 42c, 27tpi Casing
-
Cockpit
Stem
Reparto Corse by Fsa ST-OS-188/SMR-0°, Alloy 6061, raise 0°, Ext: 80mm-XS -S, 100mm-M, 120mm-L/XLHandlebar
Reparto Corse Aero shape, Aluminum 6061, reach 70mm, flare angle 16°, drop cc 130mm, size: 40cm=XS/S - 42cm=M/L - 44cm=XLGrips
Bianchi cork, black
-
Saddle
Seatpost
Reparto Corse carbon shaft UD finish, forged alloy head, 15mm offset, 31,6mm Length: 300mm-XS, 350mm-S/M/L/XLSaddle
Reparto Corse, rail steel, lenght/wide 250x148mm
Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
Geometry
Arcadex | |||||||||||||
SIZE | A | B1 | C | D | E | F | G | G1 | H | I | X | Y | WB |
XS | 440 | 522 | 425 | 75 | 120 | 596 | 74.5° | 70.5° | 50 | 416 | 365 | 565 | 1010 |
SM | 480 | 535 | 425 | 75 | 135 | 605 | 74° | 70.5° | 50 | 416 | 369 | 579 | 1018 |
MD | 520 | 550 | 425 | 75 | 150 | 610 | 73.5° | 71° | 50 | 416 | 374 | 595 | 1024 |
LG | 550 | 565 | 425 | 75 | 165 | 626 | 73.5° | 71° | 50 | 416 | 384 | 609 | 1039 |
XL | 580 | 585 | 425 | 75 | 180 | 640 | 73° | 71° | 50 | 416 | 394 | 623 | 1054 |
