Bianchi OLTRE 140TH RC

Tech specs

• Frameset

  1. Frame

     Bianchi Oltre RC carbon High Modulus, Aero shape, only electronic groupsets, fully internal cable routing, headset 1"1/4 - 1"1/4, direct mount brakes, BB-PressFit 86.5x41 sizes 47-50- 53-55-57-59

  2. Fork

     Bianchi Oltre RC full Carbon High Modulus, Aero shape, integrated head, disc, 1"1/4 head, 12x100 mm thru axle

  3. Headset

     FSA No. 54 - upper bearing MR137; lower bearing MR082R

• Drivetrain

  1. Shifters

     Shimano Dura-Ace Di2, shifter lever ST-R9270

  2. Rear Derailleur

     Shimano Dura-Ace Di2, RD-R9250, 12sp

  3. Front Derailleur

     Shimano Dura-Ace Di2, FD-R9250

  4. Crankset

     Shimano Dura-Ace, FC-R9200, 4iiii precision 3+ dual side power meter, 52x36T Crank length: 170 mm (47-53 cm); 172.5 mm (55-59 cm)

  5. Bottom Bracket

     Shimano SM-BB92-41B, press fit type for road

  6. Chain

     Shimano Dura-Ace, CN-M9100

  7. Cassette

     Shimano Dura-Ace, CS-R9200 11-30T, 11-12-13- 14-15-16-17-19-21-24-27-30T

• Brakes

  1. Brakes

     Shimano BR-R9270 Hydraulic disc brake

  2. Brake Levers

     Included in the shifter

  3. Rotor

     FRONT: Shimano RT-CL900 Center Lock with Ice Tech, 160 mm / REAR: Shimano RT-CL900 Center Lock with Ice Tech, 160 mm

• Wheels

  1. Wheels

     Bianchi Reparto Corse RC50R/RC65R SPBTech, Carbon rim, front: profile height 50 mm, rear: profile height 65 mm, 700x21c, 24h, 3K and UD carbon, HG11 body, weight: 1520 g

  2. Tire

     Pirelli P ZERO Race TLR, 28-622, 127 TPI, SPEEDCore

• Cockpit

  1. Stem

     Bianchi Reparto Corse integrated handlebar, Aero bar, Carbon, for internal cable routing, drop 125 mm, reach 80 mm Size: 90/400 mm (47-50 cm) ; 100/420 mm (53 cm) ; 110/420 mm (55-57 cm); 120/440 mm (59 cm)

  2. Handlebar

     Included in the stem

  3. Grips / Extensions

     Bianchi Arrow premium tape, 2.5 mm thickness, full black

• Saddle

  1. Seatpost Clamp

     Bianchi Custom

  2. Seatpost

     Bianchi Oltre, full carbon, aero shape, 20 mm offset length: 280 mm (47 cm); 300 mm (50-55 cm); 350 mm (57-59 cm)

  3. Saddle

     Bianchi Reparto Corse RC139 Carbon Air, 3D printed padding for adaptive stiffness, length 250 mm, width 139 mm

• Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
