Tech specs

  • Frameset

    1. Frame

      Nitron 29" full carbon monocoque, 1.5" tapered HT, BB92, seatpost diam. 27,2mm, HDM FD, PM 160mm carbon dropout 12x148mm BOOST Thru axle, internal cable routing, sizes 15-17-19-21"
    2. Fork

      Fox 32 Rythm 29" remote, 100mm travel
    3. Headset

      Fsa Orbit C-40
  • Drivetrain

    1. Shifters

      Sram NX EAGLE 1x12sp trigger
    2. Rear Derailleur

      Sram NX Eagle 12sp
    3. Crankset

      Sram NX Eagle DUB 32T, 6000 alu series arms, DIRECT MOUNT, 52mm chainline BOOST compatible, crank length: 170mm-15", 175mm-17/21"
    4. Bottom Bracket

      Sram DUB PressFit BB92, 41x92mm
    5. Chain

      Sram NX Eagle 12sp
    6. Cassette

      Sram PG1230 12sp, 11-50T
  • Brakes

    1. Brakes

      Shimano BR-MT501
    2. Rotor

      Shimano SM-RT54 CL 180mm & 160mm, Center Lock
  • Wheels

    1. Wheels

      Wtb KOM light i25 29"
    2. RearHub

      Formula CL-148S
    3. FrontHub

      Formula CL-811
    4. Tire

      Kenda Honey Badger XC Pro 29x2.20
  • Cockpit

    1. Stem

      Tec Obvius 3D forged alloy 6061, +/-7°, 1.1/8", diam. 31.8mm, ext: 70mm-15'', 80mm-17", 90mm-19/21"
    2. Handlebar

      Tec Obvius flat DB Alloy 6061-T6, width 720mm, diam. 31,8mm, 9° backsweep
    3. Grips

      T-One Rock T-GP34
  • Saddle

    1. Seatpost

      Tec Obvius, Al2014 shaft with forged head, 27.2mm, 20mm seatback, length: 350mm-15", 400mm-17/21"
    2. Saddle

      Selle Royal Seta S1, manganese rail, 277x144mm
  • Accessories

    1. Pedals

      included

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.

Geometry
