Bianchi Oltre XR3

Tech specs

• Frameset

  1. Frame

     Oltre XR3 Disc carbon w/Bianchi CV, mechanical/electronic shifting compatible, PressFit BB 86,5x41mm, flat mount calipers, thru axle 12x142mm, sizes 47-50-53-55-57-59-61cm

  2. Fork

     Bianchi Full Carbon w/Bianchi CV, Disc, 1.5" integrated head , flat mount caliper, thru axle 12x100mm

  3. Headset

     Fsa Orbit C-40-ACB

• Drivetrain

  1. Shifters

     Shimano Ultegra ST-R8020 2x11sp, hydraulic disc brake, Shimano Ultegra ST-R8025 2x11sp, smaller lever size for sizes 47/53cm

  2. Rear Derailleur

     Shimano Ultegra RD-R8000 SS 11sp

  3. Front Derailleur

     Shimano Ultegra FD-R8000

  4. Crankset

     Shimano Ultegra FC-R8000 50x34T, Hollowtech II, Crank Length: 170mm-47/53cm, 172.5mm-55/59cm, 175mm-61cm

  5. Bottom Bracket

     Shimano SM-BB72-41B

  6. Chain

     Shimano Ultegra CN-HG701-11, 11sp

  7. Cassette

     Shimano Ultegra CS-R8000, 11-12-13-14-15-17-19-21-24-27-30T

• Brakes

  1. Brakes

     Shimano BR-R8070

  2. BrakeLevers

     included w/shifters

  3. Rotor

     Shimano SM-RT800 Center Lock, diam. 160mm

• Wheels

  1. Wheels

     Fulcrum Racing 400 disc brake, 622x19c, 2 WAY FIT tubeless ready

  2. Tire

     Pirelli P7, 700 x 28c, 60TPI, Nylon breaker, Folding

• Cockpit

  1. Stem

     Reparto Corse 3D Forged alloy 6061, rise +/ - 6°, height 38mm, 1.1/8", Ext: 90mm-47/50cm, 100mm-53cm, 110mm-55/57cm, 120mm-59/61cm

  2. Handlebar

     Reparto Corse Aero Compact, alloy 6061 diam. 31,8mm, reach 74mm, drop 116mm, Size: 400mm-47/53cm, 420mm-55/59cm, 440mm-61cm

  3. Grips

     La Spirale Ribbon cork

• Saddle

  1. Seatpost

     Reparto Corse Full Carbon Aero special dimension; special Clamp type with alloy head adjustable and reversible +/- 35mm; lenght: 250mm-47cm, 300mm-50/53cm, 350mm-55/59cm, 380-61cm, Setback: 25mm/+10mm

  2. Saddle

     Fi'zi:k Antares R7, S alloy rail, 274x142mm

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.

Geometry
