Tech specs

  • Frameset

    1. Frame

      Aria E-Road Disc carbon, mechanical/electronic shifting compatible, PressFit 86,5x41mm BB, head tube 1.1/4"-1.1/8", integrated seat clamp, full carbon dropout, flat mount, QR system, OLD 135mm, sizes 47-50-53-55-57-59-61cm
    2. Fork

      Bianchi Full Carbon Disc 1.1/4">1.1/8", thru axle 12x100mm
    3. Headset

      Fsa Orbit C-33, NO.44E, 1.1/8">1.1/4"
  • Drivetrain

    1. Shifters

      Shimano Ultegra Di2 ST-R8070 2x11sp
    2. Rear Derailleur

      Shimano Ultegra Di2 RD-R8050 GS 11sp
    3. Front Derailleur

      Shimano Ultegra Di2 FD-R8050
    4. Crankset

      Shimano Ultegra FC-R8000 50x34T, Hollowtech II, Crank Length: 170mm-47/53cm, 172.5mm-55/59cm, 175mm-61cm
    5. BB

      Shimano SM-BB72-41B
    6. Chain

      Shimano Ultegra CN-HG701-11, 11sp
    7. Sprocket

      Shimano 105 CS-R7000, 11-12-13-14-16-18-20-22-25-28-32T
  • Brakes

    1. Brakes

      Shimano BR-R8070
    2. BrakeLevers

      included w/shifters
    3. Rotor

      Shimano SM-RT86, diam. 160mm
  • Wheels

    1. Rims

      Vision Trimax Alloy disc, w/rear hub Ebikemotion X35 motor unit
    2. Tire

      Vittoria Rubino Pro G2.0 Graphene 700x28
  • Cockpit

    1. Stem

      Reparto Corse 3D Forged alloy 6061, rise -8°, 1.1/8", Ext: 90mm-47/50cm, 100mm-53cm, 110mm-55/57cm, 120mm-59cm, 130mm-61cm
    2. Handlebar

      Reparto Corse Aero , alloy 6061 diam. 31,8mm, reach 74mm, drop 116mm, Size: 400mm-47/53cm, 420mm-55/59cm, 440mm-61cm
    3. Grips

      La Spirale Ribbon cork
  • Saddle

    1. Seatpost

      Aria Full Carbon Aero, clamp with alloy head adjustable and reversible +/- 35mm; length: 300mm-47/50cm, 350mm-53/61cm
    2. Saddle

      Selle Royal Seta S1, steel rails, 278x144mm
  • Motor Unit

    1. Motor

      Ebikemotion X35 Plus 250W motor unit, w/250Wh integrated battery and iWOC One remote control, BLE and ANT+ compatible

Geometry
