$0.00

Model 2021

POSITIONING
Aggressive trail e-Mtb with carbon frame, designed to climb steep mountains with total downhill control.

COURSE/TERRAIN
Mountains, everyday's trails.

END USE DESTINATION
Expert bikers, ready for the adventure and extreme performances.

KEY FEATURES:

  • Carbon frame with aluminum rear triangle
  • Travel: 150/160mm front, 140mm rear
  • Motor: Shimano Steps EP8 – 85Nm
  • Battery: 630Wh
  • Wheel size: 29x2.6, compatible with: 27.5x2.8
  • BB Height adjustability through a flip chip positioned
    on shock rocker link
  • Custom top cap w/top tube impact protection
  • Internal cable routing
  • Fox Live Valve system compatible
  • 1.5/1.5 ACR headset
  • Boost 12x148mm rear axle
  • 4 sizes: S, M, L, XL
Specifiche Tecniche

Tech specs

  • Frameset

    1. Frame

      T-Tronik Performer FS 140mm, Carbon front triangle, Alu rear triangle, 1.5" tapered HT, seatpost diam. 31,6mm, seat post clamp diam. 34.9mm, PM 180mm dropout thru axle 12x148mm, internal cable routing, sizes 38-43-48-53cm
    2. Fork

      Fox 38 Float 29" Factory, e-MTB + version, 160mm travel
    3. RearShock

      Fox Float DPS Factory
    4. Headset

      Fsa NO.77R 1.5"/ICR SB
  • Drivetrain

    1. Shifters

      Shimano XT SL- M8100R 12sp
    2. RearDerailleur

      Shimano XTR RD-M9100SGS Shadow+ Design 12sp
    3. Crankset

      Shimano FC-EM600 Alu crank 165mm, 24mm axle w/custom chainguide for 30-38T
    4. BB

      Included w/motor unit
    5. Chain

      Shimano CN-M7100, 12sp
    6. Sprocket

      Shimano CS-M7100-12, 10-51T
  • Brakes

    1. Brakes

      Shimano BL-M8120, 4 pistons brakes
    2. Rotor

      Shimano RT-MT800 Front & RT-EM810 Rear w/speed sensor magnet, diam. 203mm
  • Wheels

    1. Wheels

      DT Swiss H1700 Spline 29" 30mm
    2. Tire

      Kenda Hellkat 29x2.6
  • Cockpit

    1. Stem

      Tec Cursus, 0°, 1.1/8", diam. 35mm, ext: 50mm
    2. Handlebar

      Tec Cursus rise double butted AL7050, width 780mm, diam. 35mm, 20mm rise, 9° backsweep
    3. Grips

      T-One Rock T-GP34
  • Saddle

    1. Seatpost

      Fox Transfer Factory, diam 31.6mm, internal cable routing, travel: 100mm-15'', 125mm-17'', 150mm-19/21''
    2. Saddle

      Fi'zi:k Alpaca Terra, S alloy rail, 249x145mm

Geometry
