Bike tech specs

• sizes

  MD LG XL

• frame

  e-Omnia FX Type alloy FS 29" 150mm, 1.5" tapered HT, seatpost diam. 31,6mm, integrated seat clamp, PM 180mm dropout thru axle 12x148mm, internal cable routing inside DT, Hanger compatible UDH, sizes 43,48,53 (MD; LG; XL)

• fork

  Fox Float 36 Rhythm 29", 160mm travel

• rear shock

  Fox Float DPS Performance

• headset

  Fsa NO.55R/558 1.5"

• shifters

  Shimano Deore SL-M6100-R 1x12sp

• rear derailleur

  Shimano XT RD-M8100-SGS Shadow+ Design 12sp

• crankset

  Fsa Forged Alu, crank length 165 mm, ISIS BB axle, w/Shimano SM-CRE80-12 chainring 34T, w/custom chainguide 30-38T

• bb

  included in the motor

• chain

  Shimano CN-M7100 12sp

• cassette

  Shimano CS-M7100-12, 12sp, 10-51T

• brakes

  Shimano BR-MT520, 4 piston calipers, resin pad, w/203mm front & rear adapter, I-SPEC II compatible

• rear hub

  Formula FH-MT510-B, Center Lock, 12x148mm TA, Shimano Microspline 12sp body

• front hub

  Formula CL-811 Center Lock, 15x110mm TA

• tire

  Kenda Hellkat 29x2.6, 60tpi EMC, DTC compound

• stem

  Velomann ST97Q rise 0°, 1.1/8", diam. 35mm, length: 50mm

• handlebar

  Velomann rise, double butted AL7050, width 780mm, diam. 35mm, rise 20mm, backsweep 9°

• grips

  Rock T-GP34 single lock grip , TPR, plastic inner body, aluminium clamp

• seatpost

  Velomann dropper seatpost, diam. 31,6mm, internal remote cable routing w/remote control for 1x drivetrain, 120mm travel-43cm, 150m travel-48/53cm

• saddle

  Velomann 1285URN, manganese rail, 277x144mm

• rotor

  Shimano front:RT-64 FRONT & rear: RT-EM600 w/speed sensor magnet, diam. 203mm, Center Lock

• mudguards

  Bianchi custom mudguards

• front light

  Integrated custom front and side light made w/Spanninga

• rear light

  Integrated custom rear and side light made w/Spanninga

• motor

  Bosch Performance Line CX 250w 85Nm

• battery

  Bosch PowerTube 625Wh
