Bike tech specs

• sizes

  430 480 530

• frame

  e-Omnia FX Type alloy FS 29"- Bosch Gen4, 150mm Alloy , 1.5" tapered HT, seatpost diam.31,6mm, integrated seat clamp, PM 180mm dropout thru axle 12x148mm, internalcable routing inside DT, sizes 43,48,53 (MD; LG; XL)

• fork

  Rock Shox YARI RC 29B" Solo Air, 150mm

• rear shock

  Rock Shox Deluxe Select+ RL

• headset

  Fsa NO.55R/558 1.5"

• shifters

  Sram SX EAGLE 1x12 trigger single click for e-bike

• rear derailleur

  Sram GX Eagle 12sp

• crankset

  FSA CK-762/IS Forged Alu crank 165 mm ISIS blackFSA ISIS CrMo M15 crank arm bolts ML054EAGLE 34T CHAINRING direct mountChainguide custom 30-38T

• bb

  Included w/motor unit

• chain

  SRAM SX EAGLE 12SP

• sprocket

  Sram PG1210, 12sp, 11-50T

• brakes

  Shimano BR-MT520

• brake levers

  Shimano BL-MT501

• wheels

  Velomann ST30 TCS 2.0 29”, 30mm 29”, 32 hole drilling, Disc Only

• rear hub

  SHIMANO FH-MT400-B for CenterLock, 32h 12X148mm BOOST, 8/9/10/11 speed body

• front hub

  HB-MT400-B for Center Lock, 32holes, thru axle 15X110mm

• tire

  Kenda Hellkat 29x2.6, 60tpi EMC, DTC compound, 66-622 folding type

• stem

  Velomann +/-0°, 1.1/8", diam.35mm, lenght: 50mm

• handlebar

  Velomann rise, width 780mm, diam.35mm, rise 20mm, backsweep 9°, double butted AL7050

• grips

  T-One Rock T-GP34

• seatpost

  VELOMANN DROPPER SEATPOST, DIAM. 31,6MM, INTERNAL REMOTE CABLE ROUTING W/REMOTE CONTROL FOR 1X DRIVETRAIN, 120MM TRAVEL-43CM, 150M TRAVEL-48/53CM

• saddle

  Velomann 1285URN, manganese rail, lenght 277mm x width 144mm

• rotor

  Shimano SM-RT30, diam. 203mm

• mudguards

  BIANCHI CUSTOM MUDGUARDS

• front light

  INTEGRATED CUSTOM FRONT AND SIDE LIGHT MADE W/SPANNINGA

• rear light

  Spanninga integrated rear lights

• motor

  BOSCH PERFORMANCE LINE CX 250W 85NM

• battery

  BOSCH POWERTUBE 500WH
