Bike tech specs

• sizes

  440 480 520 400

• frame

  T-Tronik FX-Type Pro carbon sizes: 40, 44, 48, 52 - 12x148 mm thru axle dropouts - Post mount 180 disc brake type - 150mm travel front & rear - Internal cable routing in DT

• fork

  RockShox YARI RC 29", 150mm travel, 1.5 tapered HT, Maxle Stealth 15x110mm BOOST axle, minimum 180mm rotor, maximum 220mm rotor, 42mm rake, 59mm crown

• rear shock

  Fox Float DPS Performance, LV, EVOL, 3 position Lever

• headset

  FSA NO.77R 1.5"

• shifters

  Shimano Deore SL-M6100, 12sp

• rear derailleur

  Shimano Deore XT RD-M8100, 12sp

• crankset

  Shimano FC-EM600, 165MM Shimano Chainring SM-CRE80-12-B, 34T

• chain

  Shimano, CN-M6100

• sprocket

  Shimano CS-M7100-12, 10-51T

• brakes

  Shimano, BL-M6100, BR-M6120, 4 pistons

• wheels

  Velomann 29", 622x30, 32 hole

• rear hub

  Shimano FH-MT510-B, for Center Lock, 32h, 12x148 TA

• front hub

  Formula CL-811 for Center Lock, 32h 15x110mm TA

• tire

  Kenda Hellkat 29x2.6, 60tpi, 66-622

• stem

  Velomann +/-0°, 1,1/8 x diam.35mm, 50mm

• handlebar

  Velomann width 780mm, diam.35mm, rise 20mm, backsweep 9°

• grips

  T-One Rock T-GP34

• seatpost

  JD, diam.31,6mm, internal remote cable routing 100m travel --> size 40 125m travel --> size 44 150m travel --> sizes 48, 52

• saddle

  Fizik Alpaca Terra, S alloy rail, 249x145

• rotor

  Shimano SM-RT64, RT-EM600, L 203MM

• motor

  Shimano EP8, 250W, 85Nm, Display SC-EM800

• battery

  Integrated battery 630Wh
