RIDING STYLE

Designed for

Hardcore biker who makes e-mtb his main sport and wants an aggressive trail bike to have fun conquering every climb and having total control on the descent.

Riding Conditions

Riding on rough terrain with drops of less than 122 cm.

Course/terrain

Road

Mixed

Trail

City

Activity

Race

Training

Daily use

Tech specs

  • Motor Unit

    1. Motor

      Bosch Performance Line CX, 250W, 85Nm, Purion display
    2. Battery

      Bosch PowerTube 625Wh integrated battery
  • Frameset

    1. Frame

      e-OMNIA FX-Type ALU sizes: 43, 48, 53 - 12x148 mm thru axle dropouts (special dropout for external derailleur) - Post mount 180 disc brake type - 160/150mm travel front - 150mm travel rear
    2. Fork

      Fox 36 Float eBike optimized 29", Rhythm, 160mm travel, 1.5" tapered HT, QR 15x110mm BOOST axle, minimum 180mm rotor, maximum 230mm rotor, 44mm rake, 58mm crown
    3. RearShock

      FOX Float, Performance, 185/55, EVOL, 3 position lever, 0.3 Spacer, Neutral Decal
    4. Headset

      FSA NO.55R/558 1.5"
  • Drivetrain

    1. Shifters

      Shimano, SL-M6100-IR, DEORE,12-SPEED
    2. Rear Derailleur

      Shimano, RD-M8100, XT, SGS 12-SPEED
    3. Crankset

      FSA CK-762/IS Forged Alu crank 165 mm ISIS Shimano CHAINRING, SM-CRE80-12, 34T
    4. Bottom Bracket

      included in the motor
    5. Chain

      Shimano, CN-M7100, 12sp
  • Brakes

    1. Brakes

      Shimano, BL-MT501, BR-MT520, 4 pistons
    2. Rotor

      Shimano, SM-RT64, RT-EM600, DEORE, L 203MM
  • Wheels

    1. Wheels

      Velomann E30 Tubeless Ready 29", 622x30, 32 hole
    2. RearHub

      Formula CL-3248 for Center Lock, 32h, 12x148mm TA
    3. FrontHub

      Formula CL-811 for Center Lock, 32h, 15x110mm TA
    4. Tire

      Front: Pirelli Scorpion E-MTB M 29x2.6 TLR, 60tpi Rear: Pirelli Scorpion E-MTB R 27.5x2.6 TLR, 60tpi
  • Cockpit

    1. Stem

      Velomann +/-0°, 1,1/8 x diam.35mm, 50mm
    2. Handlebar

      Velomann, width 780mm, diam.35mm, rise 18mm, backsweep 8°
    3. Grips

      T-One Rock T-GP34 single lock grip, TPR, 130mm, plastic inner body, aluminium clamp
  • Saddle

    1. Seatpost

      Velomann, diam.31,6mm, internal remote cable routing, 120mm/150mm travel
    2. Saddle

      Velomann Gnd Full-fit Start Up, carbon steel rail, 262x145
  • Accessories

    1. FrontLight

      Spanninga custom integrated light, 40 lux
    2. RearLight

      Spanninga custom integrated light

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.

Collection

e-Omnia FX-Type
